DC48V High Pressure Small Centrifugal Blower Fans 15CFM High Performance
  • DC48V High Pressure Small Centrifugal Blower Fans 15CFM High Performance
  • DC48V High Pressure Small Centrifugal Blower Fans 15CFM High Performance
  • DC48V High Pressure Small Centrifugal Blower Fans 15CFM High Performance
  • DC48V High Pressure Small Centrifugal Blower Fans 15CFM High Performance
  • DC48V High Pressure Small Centrifugal Blower Fans 15CFM High Performance
  • DC48V High Pressure Small Centrifugal Blower Fans 15CFM High Performance
  • DC48V High Pressure Small Centrifugal Blower Fans 15CFM High Performance

DC48V High Pressure Small Centrifugal Blower Fans 15CFM High Performance

Place of Origin zhejiang.china
Brand Name Wonsmart
Certification ISO9001,ETL,REACH,ROHS,CE
Model Number WS145110-48-150-X300
Product Details
Brand:
Wonsmart
Part No:
WS145110-48-150-X300
Voltage:
48VDC
Air Pressure:
32Kpa
Product Weight:
1.5kg
Air Flow:
33m3/h
Speed Level:
13,000rpm-15,000rpm
Current:
3A-8.8A
Power:
144W-422.4W
Noise Level:
83[dBA]-90[dBA]
Motor Pole Pairs:
2
Motor Type:
Three Phase Brushless
Highlight:

DC48V small centrifugal blower fans

,

DC48V mini centrifugal blower

,

Small Centrifugal Blower Fans 15CFM

Payment & Shipping Terms
Minimum Order Quantity
1pcs
Price
discuss personally
Packaging Details
27*16*12cm
Delivery Time
5-7 work day
Payment Terms
T/T
Supply Ability
100set/month
Product Description

110mm small sized 32kPa 15CFM air flow 48V high pressure brushless Fuel Cell Electric Ring Blower for 10kw fuel cell. DC brushless industrial fan blower is suitable for air cushion machine/fuel cell/medical equipment and inflatables

DC48V High Pressure Small Centrifugal Blower Fans 15CFM High Performance 0DC48V High Pressure Small Centrifugal Blower Fans 15CFM High Performance 1



Blower features:



Brand name Wonsmart
High pressure with dc brushless motor
Blower type Centrifugal fan
Voltage 48vdc
Bearing NMB ball bearing
Applicable Industries Manufacturing Plant
Electric Current Type DC
Blade Material plastic
Mounting Ceiling Fan
Place of Origin Zhejiang, China
Voltage 24VDC
Certification ce, RoHS
Warranty 1 Year
After-sales Service Provided Online support
Life time(MTTF) >20,000hours (under 25 degree C)
Weight 1.5Kgs
Housing material PC
Unit size D110*H107mm
Motor type Three Phase DC Brushless Motor
Controller external
Static pressure 32kPa



Drawing:

DC48V High Pressure Small Centrifugal Blower Fans 15CFM High Performance 2



Blower Performance:



WS145110-48-150-X300 blower can reach maximum 33m3/h airflow at 0 kpa pressure and maximum 32kpa static pressure.It has maximum output air power when this blower run at 18kPa resistance if we set 100% PWM, It has maximum efficiency when this blower run at 16kPa resistance if we set 100% PWM.Other load point performance refer to below P-Q curve:



DC48V High Pressure Small Centrifugal Blower Fans 15CFM High Performance 3

DC brushless blower advantage:



(1)WS145110-48-150-x300 blower is with brushless motors and NMB ball bearings inside which indicates very long life time; MTTF of this blower can reach more than 30,000hours at 20degree C environmental temperature.

(2)This blower needs no maintence;

(3)This blower drived by a brushless motor controller have many different control functions such as speed regulation,speed pulse output,fast acceleration, brake etc.it can be controlled by intelligent machine and equipment easily.

(4)Drived by brushless motor driver the blower will have over current, under/over voltage,stall protections.





Applications:



This blower can be widely used onto vacuum machine,fuel cell.





How to use the blower correctly:



This blower can run at CCW direction only.Reverse the impeller running direction can not change the air direction.

Filter onto the inlet to protect the blower from dust and water.

Keep the environmental temperature as low as possible to make the blower life time longer.





FAQ:



Q: Can we connect this centrifugal air blower directly onto power source?

A: This blower fan is with BLDC motor inside and it needs a controller board to run.

Q: What kind of power source shall we use to drive this blower fan?
A: Generally, our customers use 24vdc switching power supply or Li-on battery.

Q: Do you also sell controller board for this blower fan?
A: Yes, we can supply adapted controller board for this blower fan.
