Place of Origin | zhejiang.china |
Brand Name | Wonsmart |
Certification | ISO9001,ETL,REACH,ROHS,CE |
Model Number | WS10690-24-200-X300 |
24V 7kpa high pressure& 24000rpm high speed dc brushless centrifugal home appliance blower with CE certification We can supply standard drivers for this blower. If you want to design your own driver, you can confirm with us.
Blower feature:
Brand name | Wonsmart |
High pressure with dc brushless motor | |
Blower type | Centrifugal fan |
Voltage | 24 vdc |
Bearing | NMB ball bearing |
Type | Centrifugal Fan |
Applicable Industries | Manufacturing Plant |
Electric Current Type | DC |
Blade Material | aluminium |
Mounting | Ceiling Fan |
Place of Origin | Zhejiang, China |
Voltage | 24VDC |
Certification | ce, RoHS |
Warranty | 1 Year |
After-sales Service Provided | Online support |
Life time(MTTF) | >20,000hours (under 25 degree C) |
Weight | 439 grams |
Housing material | PC |
Unit size | D106*H77.5mm |
Motor type | Three Phase DC Brushless Motor |
Controller | external |
Static pressure | 7kPa |
Drawing:
Blower Performance:
WS10690-24-200-X200 blower can reach maximum 100m3/h airflow at 0 kpa pressure and maximum 7 kpa static pressure.It has maximum output air power when this blower run at 4.5kPa resistance if we set 100% PWM, It has maximum efficiency when this blower run at 4.5kPa resistance if we set 100% PWM.Other load point performance refer to below P-Q curve:
DC brushless blower advantage:
(1)WS10690-24-200-X200 blower is with brushless motors and NMB ball bearings inside which indicates very long life time; MTTF of this blower can reach more than 15,000hours at 20degree C environmental temperature
(2)This blower needs no maintence
(3)This blower drived by a brushless motor controller have many different control functions such as speed regulation,speed pulse output,fast acceleration, brake etc.it can be controlled by intelligent machine and equipment easily.
(4)Drived by brushless motor driver the blower will have over current, under/over voltage,stall protections.
Applications:
This blower can be widely used onto coffe bean roaster,vacuum machine, and ventilation.
How to use the blower correctly:
This blower can run at CCW direction only.Reverse the impeller running direction can not change the air direction.
Filter onto the inlet to protect the blower from dust and water.
Keep the environmental temperature as low as possible to make the blower life time longer.
FAQ:
Q: When can I get the price?
A: Usually we quote within 8 hours after we get your inquiry.
Q: What’s your MOQ?
A: If we have the products in stock, it will be no MOQ. If we need to produce, we can discuss the MOQ according to customer’s exact situation.
Q: How long is your delivery time?
A: The general delivery time is 20-30 days after receiving your order confirmation. Another case, it will only take 1-2 days if we have the goods in stock.
